British Standard 16A 4 Gang Quad Rocker Switch — 200,000 Cycles Per Gang
The British Standard Quad Rocker Wall Switch offers four independent lighting circuits with high cycle capability per gang. Each gang has two conductive parts inside, along with a copper busbar connecting them to each other; this gives additional functionality for controlling all four circuits from one wall position. Good match to environment is achieved by supplying with 4 finishes (white, gold, grey and black) which coordinate with surrounding areas (minimalist residential through to high-end commercial applications). They accept wiring as either ‘one switch’ at ‘one location’ or as ‘two switches’ at two different locations (so that one switch controls both switches at different locations). The size of the switchplate will allow it to fit into the standard UK back plate with ease, and an option of either plastic cover or steel cover with rubber coating provides a high quality finish to coordinate with its surrounding areas. The R16307/R16308 Quad Wall Switch has been tested to comply with IEC 60669, and carries 12-year warranty, making it the ideal solution for controlling multiple independent lighting circuits from a single location.
We are a factory-direct manufacturer offering competitive wholesale pricing, OEM branding on any color PC panel, and a 12‑year warranty across the R16 series range.
Four Circuit Types — 1 Way & 2 Way, Four Color Finishes
| Model | Circuit Type | Available Colors | Application |
|---|---|---|---|
| R16307 | 4 Gang 1 Way | White / Gold / Gray / Black | Four circuits, each from one location — large kitchens, open‑plan areas, commercial spaces. |
| R16308 | 4 Gang 2 Way | White / Gold / Gray / Black | Four circuits, each from two locations — hotel corridors, large hallways, multi‑entrance rooms. |
All four switches on this switch function independently of each other. It is possible to connect gangs one and three as single pole switches so they will operate only as on/off switches and connect gangs two and four as double pole switches so they may be controlled from two separate locations, all within a single 86 x 86 mm plate. Each individual rocker switch has its own separate red copper strip(s) and silver touchpoint mechanism rated for 200,000 operations. The imported high clarity polycarbonate (PC) material is available in a white, gold, grey and black front face and is meant to match the entire R-16 product range, thus providing aesthetic continuity throughout the project.
200,000 Cycles Per Gang — Four Independent Mechanisms, Zero Shared Parts
A quad rocker switch typically operates continuously (on average 50-60 times/day) at four gang locations in a restaurant or hotel ballroom: 1) main lighting, 2) task lighting, 3) accent circuits and 4) decorative lighting (all switched from one wall). With this level of use, it is expected that a 40,000-cycle switch will have reached its lifecycle before its second year of use and will need to be replaced. However, in the same application, the R16 Series Four Gang 16A British Standard Switch will operate for more than nine years and will have a lifespan of more than 200,000 cycles per gang; thus, total switch life is expected to exceed the four-gang configuration.
Each mechanism (red copper bus bar, red copper stamping parts, red copper bush and F3.5mmx0.35mm silver alloy touchpoint) has been manufactured independently (no shared parts, no combined derating, no cross interference with the operations of any other circuit operation), and as such, the Gold Grey Black Wall Switch has been designed as a maintenance-free solution (no replacement) for facility managers operating in the UK and Commonwealth nations with respect to the replacement of quad rocker switches.
PC Panel & Dual Middle Plate Options — Four Rockers, One Rigid Platform
With the use of both an imported PC front panel that has high transparency and a high strength rating and two different middle plates (one plastic and one steel/plastic combination), this model of switch meets standard requirements as far as structural integrity are concerned for residential and light commercial applications with quadriplex outlets (quads). The plastic middle plate provides structural integrity to meet these standards for the general use of the switch; however, since there are different ways to use the switch in multiple gang configurations, we recommend that you use the combination plate with the four-way rocker switch to provide additional rigidity to the switch panel and to prevent panel flexing when different individual rockers are being used in multi-gang applications and there is no support across the full width of the switch. Both plates are guaranteed to perform for 200,000 cycles, per gang, along with a twelve-year warranty. Both plates are available in all four colors (white, gold, grey and black) to accommodate any design style that you may want to achieve, whether it is minimalistic or high-end in nature, for both residential and commercial applications.
SPECIFICATIONS
| Series | R16 series |
| Item Codes | R16307 (1 Way) | R16308 (2 Way) |
| Description | 4 Gang 1 Way / 4 Gang 2 Way Quad Rocker Wall Switch |
| Current / Voltage | 16A / 250V~ per gang |
| Mechanical Life | Max 200,000 cycles per gang |
| Number of Gangs | 4 independent rockers |
| Front Panel | Imported high‑transparent, high‑strength PC |
| Base | Imported high‑transparent, high‑strength PC |
| Middle Plate Options | Full plastic / Steel‑plastic combination |
| Switch Internal | Red copper bush, red copper stamping part, red copper bus bar, Φ3.5mm×0.35mm silver touch point (per gang) |
| Standard | IEC 60669 (British Standard) |
| Warranty | 12 Years |
| Available Colors | White / Gold / Gray / Black |
| Dimensions | H 86mm × W 86mm (British Standard back box) |
| MOQ | 2,000 pcs per item |
| Packaging | 1 pc per plastic bag | 10 pcs per inner box | 100 pcs per outer carton |
Stock This 16A British Standard 4 Gang Quad Switch in Four Colors at Factory Pricing
White, Gold, Gray, Black PC panel. 1 way & 2 way. Full plastic or steel-plastic middle plate. OEM logo, custom packaging, 12‑year warranty included. Contact us for a wholesale quotation.
IEC 60669 Certified • 200,000 Cycle Per Gang • Global Shipping
Factory-Direct Supply for Wholesale & OEM Partners
Your Source for British Standard 16A Quad Rocker Switches — Four Color Options
The R16 series 4 gang quad rocker switch brings 200,000‑cycle endurance and genuine color choice to the highest‑density British standard switch format. Stock White for volume residential projects, Gold and Gray for premium interiors, and Black for modern commercial fit‑outs — all from one factory with consistent 86×86mm dimensions. Two middle plate options let you serve both standard and heavy‑duty applications. OEM branding on any color PC panel, custom packaging, and full IEC 60669 documentation included for wholesale distributors worldwide.
Choosing the Right 16A British Standard 4 Gang Switch: Circuits, Colors & Middle Plates
A practical guide to selecting circuit types, PC panel colors, and middle plate options for high‑endurance quad rocker installations.
3 Gang vs 4 Gang — When Four Circuits Meet at One Wall Position
A 3-Gang switch can provide control of 3 different circuits from 1 wall plate, while a 4 Gang type basic British Standard switch can provide control of 4 independent lighting groups, such as; main ceiling lights, under cabinet task lighting, standalone pendant lighting above an island and accent lighting from coves using the kitchen downlights. The 4 gang switch would have the capability of running all 4 of those circuits from the same wall plate; therefore providing 1 location for running Open Plan Living Room circuits to overhead ceiling lights, wall sconces and accent ceiling lamp circuits using only 1 86mm x 86mm box and only one installation.
Color Selection — White, Gold, Gray, or Black?
White PC panel: With traditional British standard wall switches, it is suitable for all home and commercial interior styles. In high-end residential projects or hotel projects where the switch is integral to the overall design, the Gold PC panel provides warmth to the installation. The Grey PC panel is contemporary and a neutral finish. Therefore, it would also be suitable in modern apartment /s, office or industrial style interiors. Similarly, the Black PC panel provides contrast to bold or dark interior wall colours, and in premium commercial fit-out projects. All four colours are manufactured from the same high transparency PC materials which have been imported and have the same 200,000 cycle mechanism.
Middle Plate Selection for 16A Quad Rocker Panels
For four rocker panels, expect to see value in using a steel and plastic middle plate combo as all four rockers will have a layer of steel reinforcement supporting the rockers to help keep them aligned as well as to prevent tooling deformation for many decades while providing reliable operation for 16A loads. For end-users on a budget who only occasionally use the switch, a full plastic middle plate is available but for commercial or heavy usage application; its recommended to go with the steel reinforced specification.
Frequently Asked Questions
What is a 16A 4 gang British standard switch?
There are four independent rocker switches (16 amp rating) in one wall plate (86mm x 86mm) on this 16A 4 gang UK standard switch; each rocker’s independent circuit to control the corresponding circuit for lighting. The R16307/R16308 rocker switch is a four-gang rocker switch that also has 200,000-cycles of service in each rocker (mechanically operated by a red brass bush, red brass stamping parts, and the contact area being silver plated alloy). The four finishes of the panel or available are: White, Gold, Grey, and Black PC.
Does each rocker have its own 200,000-cycle mechanism?
That’s right. Every rocker in the R16 Series 4-Gang 16A Switch is connected to a dedicated red copper bus bar, red stamping parts made of red copper, bushings made of red copper, and touch points made of silver alloy with dimensions of Φ3.5mm x .35mm. In addition, each gang is independently rated for not less than 200,000 cycles of operation with no derating and no internal component sharing.
Can I mix 1 way and 2 way wiring on the same 4 gang switch?
There are four independent rockers in the 4 gang switch; therefore you can wire Gangs 1 and 3 together for a single location on/off control, then use Gangs 2 and 4 to provide two locations of on/off control for your staircase application. All of this is done from the same overall panel size of 86 mm × 86 mm. Each of the four gangs will have its own clearly labelled terminals (Common, L1, & L2).
What colors is this British standard quad rocker switch available in?
You can get the R16 Series 4 Gang Switch in four PC panel colours, which are: white (standard for all residential & commercial applications); gold (warm premium finish ideal for hotels/high-end interiors); grey (neutral-modern finish suited to modern apartments & offices); and black (bold+striking for key wall applications & high-end commercial fit outs). All of the switches do use the same imported, high-transparency, high-strength type PC material and include a 12-year warranty.
