Single Pole Wall Switch, 10A/16A, 3-Way — PC Panel, US Standard
The S-001/002 is a durable single pole switch designed for 250V applications (either 10A or 16A). The panel is made of robust PC (polycarbonate) and is designed to fit into a standard US box (Size: 75mm x 120mm). The switch is available in two configurations, “Single” or “3 Way,” allowing for one control location or two control locations respectively.
The switch mechanism itself consists of contact materials of red copper with silver plated contact points for reliable performance. A center plate (steel) connects the panel to the wall and helps keep the panel stable.
We manufacture our products and sell them factory direct. Our competitive pricing includes wholesale rates and OEM branding of the PC panel, and carries a 12-year warranty on all S-series products.
Two Circuit Types — 1 Way (Single Pole) & 2 Way (3-Way)
| Model | Circuit | US Term | Application |
|---|---|---|---|
| S-001 | 1 Gang 1 Way | Single Pole | One light from one switch — bedrooms, bathrooms. |
| S-002 | 1 Gang 2 Way | 3-Way | One light from two switches — stairs, hallways. |
PC Panel & Iron Middle Plate — Solid Everyday Performance
The wall switch uses high-transparency polymer and has an iron plate behind the polymer faceplate preventing movement during operation and providing a consistent tactile touch while using the wall switch. The size of the wall switch is designed to fit perfectly in an (approx.) 75 by 120 mm size standard USA wall box. Available in White, Gold, Gray, and Black.
SPECIFICATIONS
| Series | S series |
| Item Codes | S-001 (1 Way) | S-002 (2 Way) |
| Description | 1 Gang Single Pole / 3-Way Wall Switch |
| Current / Voltage | 10A or 16A / 250V~ |
| Front Panel | PC |
| Base / Middle Plate | High‑strength PC base / Iron middle plate |
| Switch Internal | Red copper, silver alloy contact point |
| Standard | IEC Standard |
| Warranty | 12 Years |
| Available Colors | White / Gold / Gray / Black |
| Dimensions | H 75mm × W 120mm (US standard) |
| MOQ | 2,000 pcs per item |
| Packaging | 10 pcs per inner box | 100 pcs per outer carton |
Stock This 10A/16A Single Pole Wall Switch at Factory Pricing
Available in single pole or 3-way options. Will be supplied with or without your logo, with customized packaging, and a 12-year warranty. Please contact us for a wholesale quote.
MOQ 2,000 pcs • IEC Certified • Global Shipping
Wholesale & OEM Factory Direct Supply
Your US Standard Wall Switch Supplier — Entry Level Price
The S series wall switch is our entry-level offering, providing a cost-effective switch using a PC panel that can be relied on at a low price. By using the same red copper and silver contact system as our premium range of products, we ensure that our product is of consistent quality. OEM branding on the PC panel, custom packaging and complete IEC documentation included for wholesale distributors.
Wiring a Single Pole & 3-Way Wall Switch
Installation notes for the S series 1 gang switch.
Wiring the Single Pole (1 Way) Model
Connect the incoming live wire to the common terminal, and the outgoing load wire to L1. The circuit is completed when the rocker is pressed to the “on” position.
Wiring the 3-Way (2 Way) Model
Two traveler wires connect the L1 and L2 terminals between both S-002 units. The common terminal on each switch connects to the power source or the light fixture. This allows either switch to control the light independently.
Application Use Cases
The single pole wall switch is the standard choice for bedrooms and living rooms. The 3‑way version meets US electrical code for staircases and hallways where a light must be controllable from two locations.
Frequently Asked Questions
What is a single pole wall switch?
A single pole wall switch controls one lighting circuit from a single wall location. The S-001 is a 1 way (Single Pole) switch — line in, load out — the standard US configuration for bedrooms, bathrooms, and living areas.
What is the difference between single pole and 3-way?
A single pole switch controls one circuit from one location. A 3-way switch works in pairs to control a single circuit from two locations — the standard US code requirement for staircases and hallways. The S-002 is a 2 way (3-Way) switch designed for two‑location control.
Can a 3-way switch be used as a single pole?
Yes, the S-002 3-way switch can be wired as a single pole by using only the common terminal and one traveler terminal (L1), leaving the second traveler (L2) unused. This allows you to standardize on one model for your entire project.
Is this switch compatible with US wall boxes?
Yes, the 75×120mm panel is the standard US form factor, designed to mount directly into North American wall boxes without adapters or modifications.
