SPECIFICATIONS
| Series | T‑B Series |
| Item Codes | T-B-010/046/047/052/053 |
| Description | 1 Gang 2 Pin Socket / 2P American Outlet |
| Current / Voltage | 16A / 250V~ |
| Front Panel Options | PC / Acrylic / Glass |
| Base & Middle Plate | Imported high‑strength PC base + Iron middle plate |
| Socket Contact | Copper |
| Standard | IEC Standard |
| Warranty | 12-Year Warranty |
| Available Colors | White / Gold / Gray / Black |
| Dimensions | H 75mm x W 120mm |
| MOQ | 2,000 pcs per item |
| Packaging | 10 pcs per inner box | 100 pcs per outer carton |
2 Pin Socket 16A – American Socket with PC, Acrylic or Glass Front Plate/Panel
The T-B-010/046/047/052/053 is a 2 Pin – 16A Socket designed to fit North American outlet boxes. The T-B-010/046/047/052/053 is available with three different front panel finishes: PC, Acrylic, or Tempered Glass. This US standard American Outlet (1 Gang) is capable of full 16A/250V power point in a standard 75mm x 120mm size, and has numerous benefits and features including copper internal contacts, rigid PC base with iron center plate, IEC compliant, and a 12-Year Warranty. Because there are many different solutions for the same outlet, this is an excellent option when the outlet finish is as important to the specifier or user/operator as the outlet electrical performance.
One Socket, Three Panel Materials:
A PC Front Panel for cost-effective large volume production, Acrylic Front Panel for a glossy, scratch-resistant surface, or Tempered Glass Front Panel for a premium, smooth touch finish. The copper internal contacts and the strong, rigid PC Base, providing excellent electrical connectivity and retention, are consistent across all three panels. Thus, the panel material is a matter of visible finish only, not of electrical compromise.
Full 16A Rating – Standard US Size:
This is a 2 Pin socket rated at 250V/16A for general-purpose and high draw loads. The 75mm x 120mm panel mounts into all standard North American wall boxes without an adapter.
Copper Contacts and Reinforced Finish
The socket contacts are made of solid copper, allowing for maximum conductivity and retention of the plug over many cycles of plugging and unplugging. The socket base is constructed of high-strength PC material and has a full-width iron center plate between them. All three of these define the strength of the assembly. Because of the criticality of the design for a socket outlet, larger designs can become loose over time with repeated plug insertion/removal. The use of an iron plate to support the panel prevents this from happening, allowing for a flush fit over the long term.
Factory-Direct Supply for Wholesale & OEM Partners
Your Source for American Standard 2 Pin Sockets
The 2 pin socket is produced with the full T‑B series line to ensure consistent quality and aesthetics across your catalog. Three front panel materials — PC, acrylic, and glass — create distinct product tiers ranging from economy to luxury, all with the same 75×120mm footprint and 16A specification. Factory-direct pricing, OEM branding on any panel material, and logistics support are tailored for importers and distributors serving North American and global markets.
Where This 2 Pin Socket Fits Your Project
Application notes for specifying an American outlet in residential, commercial, and hospitality installations.
Application Use Cases
For residential bedrooms and living areas, this 2 pin socket provides a clean power point for lamps, chargers, and small appliances — specify PC for volume builds or glass for a premium finish. In hotels and hospitality, the glass panel American outlet matches luxury switch plates for a cohesive guest‑room aesthetic. For offices and commercial spaces, the 16A rating handles desktops, monitors, and office equipment reliably, while the acrylic panel offers scratch resistance for high‑traffic areas.
Installation & Wiring Note
Mounts directly into standard 75×120mm North American wall boxes. Terminals are clearly marked for line, neutral, and ground. The iron middle plate keeps the panel rigid against the wall — on a socket outlet, this reinforcement is especially important because repeated plug insertion and removal can loosen lesser designs over time.
Frequently Asked Questions
What is a 2 pin socket?
A 2 pin socket is a wall power outlet with two slots or holes that accepts a 2‑prong plug. It provides live and neutral connections without a dedicated earth/ground pin. The T‑B series 2 pin socket is a 1 gang 16A American outlet designed for double‑insulated appliances like lamps, phone chargers, TVs, and small kitchen devices.
What is a 2 prong electrical plug called?
In North America, it is commonly called a 2‑prong plug, Type A plug, or NEMA 1‑15 plug. In Europe and Asia, similar ungrounded plugs are often referred to as Europlugs (Type C). The T‑B series 2 pin socket is compatible with the corresponding ungrounded plug type for its target market, providing a standard 16A power connection.
Are two pin sockets safe to use?
Yes, 2 pin sockets are safe when used as intended — with double‑insulated appliances that do not require an earth connection. Modern double‑insulated devices have an extra layer of internal protection, marked by a square‑within‑a‑square symbol. The T‑B series 2 pin socket is IEC compliant and built with copper contacts and a fire‑resistant PC base, meeting international safety standards for ungrounded outlets.
Are two pin plugs outdated?
Two‑pin plugs are not outdated — they remain the global standard for millions of double‑insulated devices. While grounded (3‑pin) outlets are required for metal‑cased appliances and wet areas, 2 pin sockets are still widely specified in living rooms, bedrooms, and offices for lamps, entertainment systems, chargers, and small appliances. The T‑B series 2 pin socket serves this exact market: a modern, 16A‑rated American outlet with a choice of panel finishes for contemporary interiors.
