British Standard 13A 2 Gang MF Switched Socket — Phosphor Copper Double Wall Socket, White PC Panel
The R16408M is a BS 13A 2 gang MF switched socket that has a high‑phosphor copper contact material, which fulfills the engineering approach chosen where plug insertion and removal takes place daily and on a frequent basis. This phosphor copper socket is a dual socket of the common BS1363, mounted on one 86 x 146mm wall plate, with two independent outlets, each having an SP rocker switch and a neon indicator which provides a visual indication that power is present.
The MF (Multi-Function) identifies the combined functional design as having two power outlets, two switches and two neon indicators, all contained within a single seamless panel or enclosure. The phosphor copper contacts have a greater amount of springiness than standard brass contacts, thus providing a stronger grip on the pin after many thousands of insertions. The R16408M is manufactured by a specialist manufacturer of phosphor copper sockets using red copper switch internals and a Φ3.5mm x 0.35mm silver alloy contact point per gang. The R16408M is offered in four colors of high transparency imported PC. Two options are available for the middle plate. The R16408M is certified to IEC 60884 and is covered by a 12-year warranty.
We are a factory-direct double MF switched socket manufacturer offering competitive wholesale pricing, OEM branding on any color PC panel, and a 12‑year warranty across the R16 series range.
Phosphor Copper vs 62 Brass — Why the Socket Contact Material Matters for 2 Gang
| Feature | R16408M (Phosphor Copper) | R16408 (62 Brass) |
|---|---|---|
| Socket Contact Material | 0.7mm high phosphor copper | 0.7mm high purity 62 brass |
| Key Property | Superior elasticity — maintains grip longer | Good conductivity — standard UK socket material |
| Best For | High‑use locations — hotels, offices, kitchens | Standard residential — living rooms, bedrooms |
| Certification | IEC 60884 | IEC 60884 / BS1363 |
The main distinction between 2 gang switched sockets is the electrical connection material used. Phosphor copper is much more elastic than 62 brass and will keep its spring tension and pin grip through significantly more insertion cycles without the gradual relaxation that brass contacts experience as time goes by. This difference is magnified in applications that use dual gang switched sockets because both sockets are typically in frequent use when compared to single switched socket applications, such as kitchen countertops where kettles and toasters are plugged in/out on a daily basis and office desks where laptops and chargers are plugged in/out daily. The R16408M MF double switched socket has phosphor copper contacts and is therefore the correct specification for these high use dual socket applications. The R16408 with 62 brass contacts is still the most cost effective choice for use in standard length installations because the plugs are typically left plugged in for long periods of time. Both models should be stocked in order to provide customers with a clear good-better upgrade path within the same R16 series design.
Matching the R16 Series — 2 Gang MF Phosphor Copper Socket Within the Same Aesthetic
This double MF socket white PC is a unit of the complete R16 range with all R16 electrical accessories using imported high transparent version of PVC; the 4 colour finishes are also the same. The R16408M phosphor copper has been specifically designed to be fitted with a standard R16408 brass contact, with both having identical external appearance, but phosphor copper contact materials will provide a genuine upgrade for use in high demand environments. The socket dimensions are 86mm x 146mm, suitable for use with standard double gang British back box installations. The R16408M will come in White, Gold, Grey or Black. There will be 2 middle plate options available – either all plastic for standard installations or a combination of steel and plastic to increase strength/rigidity. The R16408M phosphor copper socket is IEC 60884 compliant therefore backed by a 12 year warranty from manufacturer.
SPECIFICATIONS
| Series | R16 series |
| Item Code | R16408M |
| Description | 13A 2 Gang MF Switched Socket with Neon (Phosphor Copper Contacts) |
| Socket Rating | 13A / 250V~ per socket |
| Socket Configuration | 2 gang MF — two independent BS1363 outlets |
| Switch Type | SP (Single Pole) with neon indicator per socket |
| Product Lifetime | 15,000 cycles per socket (socket insertion) |
| Socket Standard | UK 3‑pin (BS1363 compatible) |
| Front Panel | Imported high‑transparent, high‑strength PC |
| Base | Imported high‑transparent, high‑strength PC |
| Middle Plate Options | Full plastic / Steel‑plastic combination |
| Switch Internal | Red copper bush, red copper stamping part, red copper bus bar, Φ3.5mm×0.35mm silver touch point (per gang) |
| Socket Contact | 0.7mm high phosphor copper, integrated structure copper |
| Standard | IEC 60884 |
| Warranty | 12 Years |
| Available Colors | White / Gold / Gray / Black |
| Dimensions | H 86mm × W 146mm (double gang British Standard back box) |
| MOQ | 2,000 pcs per item |
| Packaging | 1 pc per plastic bag | 5 pcs per inner box | 50 pcs per outer carton |
Stock This 13A British Standard 2 Gang MF Phosphor Copper Switched Socket in Four Colors at Factory Pricing
White, Gold, Gray, Black PC panel. Two independent 13A outlets with neon indicators. 0.7mm phosphor copper contacts. Full plastic or steel-plastic middle plate. OEM logo, custom packaging, 12‑year warranty included. Contact this phosphor copper socket manufacturer for a wholesale quotation.
IEC 60884 Certified • Phosphor Copper Contacts • Global Shipping
Factory-Direct Supply for Wholesale & OEM Partners
Your Source for British Standard 13A 2 Gang MF Phosphor Copper Double Switched Sockets — Factory Direct
As a specialist phosphor copper switched socket manufacturer, we produce the R16408M on our own production lines — giving your wholesale business a genuine material upgrade option for high‑use dual‑socket locations. Stock White for volume residential and hotel projects, Gold and Gray for premium interiors, and Black for modern commercial fit‑outs — all with the same two independent 13A outlets, 0.7mm phosphor copper socket contacts, red copper switch mechanisms, and neon indicators per socket. Stock alongside the R16408 (2 gang SP, 62 brass) and R16492C (2 gang DP USB) to offer customers a complete tiered 2 gang range from one British standard double MF socket factory. OEM branding on any color PC panel, custom packaging, and full IEC 60884 documentation included for wholesale distributors worldwide.
R16408M vs R16408: Choosing the Right 2 Gang Switched Socket — Phosphor Copper or 62 Brass?
A practical guide to selecting the correct 2 gang socket contact material for different use environments, plus color and middle plate options.
R16408M (Phosphor Copper) vs R16408 (62 Brass) — Which One for Your Project?
The choice will depend on how you expect to use the dual-socket location. Phosphor copper (R16408M) is significantly more elastic than brass because it will maintain its spring tension and grip force for many more insertion cycles than brass. For hotel rooms, office desks, commercial kitchens, and any other location where both socket plugs will be inserted and removed regularly, choose the phosphor copper double switched socket. Brass (R16408) provides outstanding conductivity for a lower price point, so this option is best for the average homeowner or apartment resident who plugs and unplugs their socket(s) less frequently. In addition to sharing the same physical dimensions (86×146 mm), R16 series colour finishes, and 12-year warranties, the sockets differ by way of superior-quality internal material; otherwise, there will be no noticeable distinction between the two when viewed from outside.
Why Phosphor Copper Makes Sense for 2 Gang Locations
A two-outlet socket is usually used to share two electrical devices from one wall location, such as kitchen counters and workstations, or from one piece of furniture such as an entertainment center. These outlets are frequently used to plug and unplug devices into and out of each outlet. As time passes, brass contacts (which are typically used) can lose their spring tension, causing the connection to become loose, and can eventually overheat. The R16408M MF double-duplex two-circuit with spring-loaded phosphor copper contacts maintains consistent contact pressure for each circuit during their full use life of 15,000 cycles without losing contact tension — a significant long-term reliability benefit for use in dual-circuit and dual-use outlets where the electrical devices will be frequently put into and out of service.
Color Selection — White, Gold, Gray, or Black?
White PC panel: The gold color panel is a warm, metallic hue that can be used in hotels and luxurious homes. The gray color panel has a neutral, modern look, which makes it perfect for large modern buildings and commercial businesses. The black color panel provides a contrasting color in high-end buildings and for the construction of large commercial businesses. All of the four color options use the same imported, highly transparent material made from polycarbonate, phosphor copper contacts, and each panel is sold with a 12-year warranty.
Frequently Asked Questions
What is a 2 gang MF switched socket?
There are 13A outlets for two different independent power supplies, using a 2-gang MF switched socket with 2 different rockers and lights. These are mounted onto one panel using Multi Function (MF) design, which allows for easier installation and includes the socket, switch and neon. The R16408M is a 2 gang MF switched socket with neon to British Standards. Each of the outlets has its own single pole (SP) rocker switch and indicator light, both supply power through high phosphor copper contacts of 0.7mm for long lasting elasticity and pin retention.
What is the difference between phosphor copper and brass socket contacts?
Compared to 62 brass, phosphor copper has greater elasticity and retains its spring tension and pin grip longer across multiple insertions due to less gradual relaxation than through traditional brass contacts. For these reasons, phosphor copper is a better selection than brass for common use in locations such as hotel rooms, office desktops, and commercial kitchens. While brass is an acceptable conductor of electricity and is relatively inexpensive, it is not as common of a metal for residential electrical outlets. The R16408M uses a 0.7mm high phosphor copper contact; the R16408 uses a 0.7mm high purity 62 brass contact.
Can each socket be switched independently?
To clarify, there are two sockets in the R16408M 2 Gang MF Socket that can have their power supplied from the mains. Each socket will have its own SP switch and neon indicator. Hence, you can turn the kettle socket off and keep the toaster socket on as they have their own circuits and supplies to turn on or off.
The two sockets are supplied from separate supplies with independent switches and their neon indicators within the same 146mm panel.
What colors is this British standard 2 gang MF phosphor copper socket available in?
There are four color options available for this line of electrical wiring devices: white (a classic choice for both residential and commercial installations); gold (a luxurious choice suitable for high-end projects); grey (a contemporary choice ideally suited for modern office buildings); and black (the most strikingly contrasting color in this line, suitable for commercial projects as well as high-end spaces). All four colors are manufactured from an identical high-quality, high-transparency, high-strength material and carry an industry leading warranty of twelve (12) years with respect to manufacturing defects.
