SPECIFICATIONS
| Series | DN71 series |
| Item Code | DN71588C |
| Description | Double MF 3 Pin Switched Socket with Neon & USB Type-C Fast Charging Port |
| Socket Rating | 13A / 250V~ per socket |
| Socket Configuration | 2 gang — two independent MF 3 pin outlets |
| Socket Type | MF 3 pin multi-standard with switch & neon per socket |
| USB Port | Type-C fast charging port |
| Switch Type | SP (Single Pole) with neon indicator per socket |
| Target Markets | Ghana, West Africa — mixed-standard regions |
| Front Panel Options | PC / Tempered Glass / Aluminum |
| Base | PC |
| Middle Plate Options | Steel / Plastic-wrapped steel |
| Switch Contact | Red copper, Φ3.0×25mm silver alloy touch point (per gang) |
| Socket Contact | 0.6mm phosphor copper with fix circle ring (per socket) |
| USB Protection | Over‑current, over‑voltage, short‑circuit protection built in |
| Surface Finish | Baby skin printing — ultra‑smooth, fingerprint‑resistant, easy to clean |
| Standard | IEC Standard |
| Warranty | 12 Years |
| Available Colors | White / Gold / Gray / Black |
| Dimensions | H 88mm × W 146mm (double gang back box) |
| MOQ | 20GP container |
| Packaging | 1 pc per plastic bag | 5 pcs per inner box | 50 pcs per outer carton |
Double MF + USB-C vs Double MF Standard — Fast Charging Built Into Universal Design
| Feature | DN71588C (Double MF + USB-C) | DN71408M (Double MF Standard) |
|---|---|---|
| USB Charging | Built-in Type-C fast charging — charge devices directly from the wall | No USB — requires separate plug-in adapter |
| Power Outlets | Two MF 3 pin sockets — both stay free for appliances | Two MF 3 pin sockets — one occupied if USB adapter is used |
| USB Independence | USB charges even when both sockets are switched off | N/A — no USB port |
| Best For | Kitchens, TV points — two appliances + device fast charging | Two appliances only — no charging needed |
Dual USB Universal Socket — Fast Charging for West Africa’s Mobile-First Generation
| Feature | DN71588C (Ghana USB Socket) | Standard USB Adapter Setup |
|---|---|---|
| Wall Appearance | Clean — USB built flush into the wall plate | Cluttered — adapter protrudes from the wall |
| Power Outlets | Both MF sockets available for appliances | One socket permanently occupied by USB adapter |
| Charging Speed | Fast charging — optimized Type-C output | Depends on adapter quality — varies widely |
| Safety | Built-in over‑current, over‑voltage, short‑circuit protection | Depends on adapter — cheap adapters may lack protection |
Baby Skin Printing Surface — The Signature DN71 Tactile Experience
| Finish | Baby Skin Printing Treatment |
|---|---|
| PC Panel | Imported high‑transparent polycarbonate with baby skin printing — silky smooth, fingerprint‑resistant, and exceptionally easy to clean. |
| Tempered Glass | Glossy tempered glass with baby skin printing — luxurious reflective surface that resists smudges and feels like silk to the touch. |
| Brushed Aluminum | Brushed aluminum with baby skin printing — metallic industrial aesthetic combined with an unexpectedly smooth, soft tactile finish. |
Double MF3-Pin Switched Socket with USB Type-C – Universal Ghana Socket with Fast Dual USB Charging and Baby Skin Prints
The DN71588C is a dual MF 3 Pin switched socket that comes with USB Type-C technology and combines two independent universal outlets and a USB Type-C fast charging port in a single wall plate, whose actual dimensions are 88x146mm. The demand for fast-charging equipment in Ghana and other West African countries is quite high hence the manufacturer has focused on mobile phones, the country’s primary internet devices, and has developed this product to cater to these needs. The sockets can operate with different types of plugs including British BS 3 pin, European round pin, and also other local plug variants. Each of the two MF sockets can accept any plugs independently of each other. So we can connect some kettle with the UK plug and a fan with the European one at the same time. The integrated USB-C port can charge modern smartphones, thus leaving both MF sockets free. The product is offered in three different fashionable panel materials – PC, toughened glass, and brushed aluminum.
Based in the factory, we are manufacturers who sell our products at wholesale prices, offer any panel material with OEM branding and provide the 12-year warranty on the entire DN71 series.
Fast Charging USB + Dual Universal Outlets — The Complete West African Power Solution
This socket design for Ghana and the USB socket of West Africa is especially made for a generation focused on mobile. Smartphones are used in Ghana and the entire West African region for banking services, communications, business business, and entertainment. People use it on a daily basis and for that, they need charging every day.
The DN71588C meets this requirement by offering a fast charging Type-C port for optimal charging of new Android and iOS devices from the wall with no need for the adapter occupying one of the power outlets. The MF 3-pin sockets meet the needs of different appliances. The MF sockets come with their own independent rocker switches and neon indicators, which makes them easy to use.
The phosphor copper contacts of 0.6mm ensure constant grip force with devices from UK, Europe, and Africa since all plugs are made the same for all countries. The Type-C USB module is equipped with self-contained protection. The DN71588C socket is IEC certified and comes with a clear 12-year warranty from the manufacturer.
Matching the DN71 Series — Fast Charging Universal Socket in the Same Baby Skin Finish
This fast-charging socket with baby skin printing is named the DN71 series and has similar quality of panel materials like other products in the DN71 series such as DN71 single MF socket, DN71 double MF standard socket, DN71 double UK socket, DN71 switch, and DN71 DP isolators. A DN71588C double MF USB socket used for the living room charging point can be used along with the DN71 single MF socket and DN71 switch like having DN71 double MF socket in other places of your home or room in Ghana. Its dimensions are 88×146mm and are used in a standard double gang back box. You can find it in White, Gold, Gray, and Black colors in all three panel materials.
Stock This Fast Charging Double MF Universal USB-C Baby Skin Printing Switched Socket for West Africa at Factory Pricing
PC, tempered glass, or aluminum panel with baby skin printing finish. Twin MF 3 pin universal socket with independent switches, neon indicators, and integrated Type-C fast charging USB. OEM branding, custom packaging, 12‑year warranty included. Container‑level supply available. Contact us for a wholesale quotation.
IEC Certified • 20GP Container Supply • Global Shipping
Factory-Direct Supply for Wholesale & OEM Partners
An excellent place to get fast-charging dual USB sockets that easily work all through Ghana and West African markets.
DN71588C USB Type-C Double MF 3 pin Switch Socket makes the DN71 series the most comprehensive twin-outlets universal power and charging solution, which has been specially made for the countries of Ghana and West Africa, equipped with necessary features for everyday use that include various plug types, appliances, and fast charging of smartphones. Two independent MF outputs accept plugs of the UK, European and local standard with separate switches and neon lights. Type-C connector offers optimal charging speed in any situation and does not take up an outlet. The available materials for front panelling can be PC, tempered glass and brushed aluminum. One can offer them together with DN71408M (double MF standard), DN71405M/DN71407M (single MF) and DN71477 (5 pin MF).
Fast Charging USB + Dual Universal vs Standard Universal: Choosing the Right Socket for Ghana & West Africa
A practical guide to specifying fast charging dual USB universal sockets for West African electrical installations.
DN71588C (Fast-Charging USB + Dual Universal) vs DN71408M (Double MF Standard) — Which One Should You Choose?
The DN71588C high-speed charging USB socket fits perfectly in the Ghanaian and West African areas where there is a need to power two appliances and charge a smartphone at the same time from one position on the wall — in hotel bedrooms, kitchen countertops, living room TV points, and even at office desks. With the integrated Type-C fast charging port, the gadget provides the highest possible charging speed for all the modern smartphones without using the socket. The DN71408M double MF standard socket is ideal for the situations where two appliances are in need of power while USB charging is available in another location, or even not required at all. Both sockets have the same size of 88×146mm, universal MF design, and baby skin printing.
Why Fast Charging Matters for West African Markets
Smartphones are the major computing devices used daily by a vast number of people in Ghana and West Africa, from mobile banking to business activities, communication, education, and entertainment purposes. The smartphone becomes useless if it runs out of battery power, meaning the user may lose access to vital services. A fast charging USB socket DN71588C eliminates the need for a power adapter, as it allows Type-C fast charging straight out from the mains, providing fast charging rates. Fast charging has now become routine in hotels, serviced apartments, and modern residential buildings.
Panel Material Selection — PC, Glass, or Aluminum?
PC with baby skin printing: An economical option with a luxurious silky finish — the ideal solution for home and business projects. Tempered Glass with Baby Skin print: shining and smooth to the touch — the best choice for hotels and premium housing in West Africa. Brushed Aluminum with Baby Skin print: bright industrial design with a surprisingly soft feel — suitable for modern business and hospitality projects. All three use the same fast charging USB + dual MF design and come with the same 12-year warranty.
Frequently Asked Questions
What is a fast charging dual USB universal socket?
The dual USB fast charging universal socket has two separate multi-standards electrical outlets and a fast charging Type-C USB port in just one wall socket box. The DN71588C model is a two MF socket device belonging to the DN71 series featuring fast charging USB-C — both MF sockets are compatible with UK BS 3‑pin, European round‑pin, and regional plugs, plus the integrated USB Type-C port supports fast charging smartphones without blocking either power socket. Each socket features a rocker switch and a neon indicator that allows for big-time savings in terms of space and convenience due to its independent usage.
Does the USB-C port still fast charge when both socket switches are off?
The USB Type-C fast charging port on the DN71588C indeed works independently from both switching sockets. The USB module is powered directly from the mains supply and continues to fast charge devices, even when both rocker switches are OFF and the two 13A sockets are isolated. The neon status indicators are only intended to indicate the state of the sockets and do not indicate that the USB is powered, which is always ready to charge, as long as the circuit is live at the consumer unit.
Is this dual USB universal socket suitable for the Ghanaian market?
Certainly, the DN71588C was engineered as a Ghana socket and a USB wall outlet for the West African marketplace. Typically, many forms of both UK and European plugs are connected with Ghanaian electrical fittings — namely, the MF 3-pin configuration enables plug compatibility without any need for multiple types of adapters. The built-in Type-C quick charging socket also meets the requirements of fast cellphone charging which is particularly needed for its mobile-first economy.
What panel materials is this fast charging dual USB universal socket available in?
The double MF series DN71 3 pin switched socket with the quick charging USB Type-C comes in three types of front panels featuring the baby skin printing process: imported clear PC (cheap, tough and silky to the touch), glass (shiny and smooth, resistant to fingerprints), and brushed aluminum (having a metallic industrial design with a surprisingly soft tactile feel). All three materials have the same sizes (88×146mm), fast charging dual USB universal design and 12 years warranty.
